Contractor Quality® Door Closer Hinges

Product: Contractor Quality® Door Closer Hinges.

Product Type: Spring-Loaded Door Closer Hinge.

Size: 4-1/2″ x 4-1/2″.

Material: Steel or Stainless Steel.

Operation:
Non-handed for right- or left-hand doors.
Adjustable spring tension with included adjustment wrench.

Fire Rating:
UL Listed.
1/2-Hour Fire Rated.

Application:
Designed for self-closing commercial doors.
Fits standard 4-1/2″ x 4-1/2″ mortise hinge preparations.
Can be used with ball bearing hinges on the same door.

Features & Benefits:
Spring-loaded hinge automatically closes the door after opening.
Adjustable spring tension can be set before or after installation.
Anti-friction bearing design handles vertical and horizontal loading.
Suitable for commercial, institutional, and fire-rated openings.
Available in steel and stainless steel finishes.

Finish Options:
Prime Coat.
Brass Plated.
Dull Chrome.
Oil Rubbed Bronze.
Polished Brass.
Polished Chrome.
Duranodic.
Stainless Steel.

Installation Information:
Use UL hinges based on door weight:
Up to 60 lbs. – One UL hinge.
Up to 110 lbs. – Two UL hinges.
Up to 160 lbs. – Three UL hinges.
Over 160 lbs. and 1-3/4″ thick – Four UL hinges.
Includes mounting screws.
